APRILIA WHEEL GUIDE
Kineo Wheels for Aprilia Tuareg 660 & Tuareg Rally: Fitment, Sizes & Upgrade Guide
Factory wheel specifications, Standard vs Rally differences, Kineo construction, fitment requirements and custom wheel configuration.
The Aprilia Tuareg 660 is built around a 21-inch front and 18-inch rear spoked-wheel layout, but not every Tuareg uses exactly the same wheel specification. The standard model and the Aprilia Tuareg 660 Rally differ in rim width and tube configuration, which is important when choosing aftermarket wheels.
Aprilia Tuareg 660 Wheels: Know the Factory Setup First
The standard Aprilia Tuareg 660 uses a 2.15 × 21-inch front spoked rim and a 4.25 × 18-inch rear spoked rim. The original tyre sizes are 90/90-21 at the front and 150/70 R18 at the rear. Most importantly, the standard motorcycle is already designed to run tubeless tyres.
STANDARD TUAREG 660 Factory Wheel Snapshot
01 FRONT 2.15 × 21
90/90-21 original front tyre size.
02 REAR 4.25 × 18
150/70 R18 original rear tyre size.
03 FACTORY SYSTEM Tubeless
The standard motorcycle already leaves the factory with a tubeless spoked-wheel setup.
That means riders looking for replacement or aftermarket Aprilia Tuareg 660 wheels should not assume that Kineo is required simply to eliminate inner tubes. On the standard model, the real reasons to consider Kineo are the wheel design, custom configuration and the opportunity to build a wheel set specifically around the motorcycle.
For owners planning other Aprilia Tuareg 660 accessories, the wheels can also become one of the most visible elements of a larger custom build.
Why Choose Kineo for the Tuareg 660?
Kineo uses a purpose-built tubeless spoked-wheel system in which the spoke attachment points remain outside the airtight section of the rim bed. This allows the wheel to support tubeless tyre use without relying on a conventional inner tube or a temporary taped sealing conversion.
KINEO CONSTRUCTION Tubeless Spoked-Wheel Architecture
01
Aluminium Components
CNC-machined 7000-grade aluminium rims and aluminium hubs form the main structure of the wheel assembly.
02
Stainless-Steel Spokes
Stainless-steel spokes create the distinctive Kineo appearance while remaining separate from the sealed tyre chamber.
03
Custom Finishes
Rim, hub, spoke and nipple finishes can be selected independently to create a wheel set around the motorcycle.
For a standard Tuareg 660, this is better understood as an alternative wheel system rather than a tubeless conversion. The original motorcycle already provides tubeless functionality, so the decision should be based on what Kineo adds to the complete build.
Some riders may prefer the distinctive Kineo spoke pattern. Others may want a particular combination of rim and hub finishes that works with the motorcycle's graphics, bodywork or other Aprilia Tuareg 660 accessories.
Aprilia Tuareg 660 Rally: A Different Wheel Specification
The Aprilia Tuareg 660 Rally needs to be considered separately. Although it belongs to the same Tuareg family, its factory wheel specification is not identical to the standard motorcycle.
STANDARD
Tuareg 660
21″ FRONT
/ 18″ REAR
Front Rim 2.15 × 21
Rear Rim 4.25 × 18
Factory Setup Tubeless
Kineo is primarily an alternative wheel construction and customization choice for the standard model rather than a basic tube-to-tubeless conversion.
RALLY
Tuareg 660 Rally
21″ FRONT
/ 18″ REAR
Front Rim 1.85 × 21
Rear Rim 4.00 × 18
Factory Setup Tube-Type
For Rally owners, a dedicated tubeless wheel system can become an additional part of the upgrade decision alongside wheel construction and customization.
STANDARD ≠ RALLY
21/18 does not mean identical wheel fitment.
Rim width, factory tyre configuration and the complete motorcycle application still need to match the exact version.
This is why not all Aprilia Tuareg 660 wheels should be treated as interchangeable simply because both motorcycles use a 21-inch front and 18-inch rear format. The exact model and production year should be confirmed before a wheel set is ordered.
Fitment Matters More Than Rim Diameter
A correct wheel order begins with the exact motorcycle. Diameter is only one part of the fitment; the complete wheel system also has to work with the brake, ABS, axle and drivetrain arrangement of the bike.
CONFIRM BEFORE ORDERING
Build the Wheel Around the Exact Motorcycle
- Exact motorcycle model
- Production year
- Standard Tuareg or Rally
- Front and rear wheel specification
- Brake disc arrangement
- ABS-related components
- Sprocket and rear-wheel hardware
- Axle, bearings and spacers
- Suspension modifications
- Previous wheel or brake modifications
Kineo wheel sets for supported motorcycles are configured around the specific application rather than supplied as a universal adventure-bike wheel. In many supported installations, original-style brake, ABS and drivetrain components can continue to be used where applicable, but compatibility still needs to be confirmed for the actual motorcycle.
This becomes especially important when comparing aftermarket Aprilia Tuareg 660 wheels for motorcycles that already have non-standard brake discs, suspension components, axle hardware or drivetrain modifications.
Choosing the Right Kineo Wheel Configuration
Once technical fitment has been confirmed, the visual specification can be selected. Kineo allows key wheel components to be configured separately, making it possible to create either a restrained factory-inspired appearance or a much more individual build.
01 MODEL
02 YEAR
03 VERSION
04 WHEEL SIZE
05 FINISH
01
Rim
The rim creates the strongest visual outline and can remain subtle or become the main colour element of the wheel.
02
Hub
Hub colour controls the centre of the wheel and can either blend with the motorcycle or create stronger contrast.
03
Spokes
The spoke finish changes how strongly the Kineo wire structure stands out against the rim, tyre and surrounding components.
04
Nipples
Nipple colour adds a smaller accent and works best when it repeats another detail already present elsewhere on the motorcycle.
For riders already considering premium Aprilia Tuareg 660 accessories, a wheel set has a much stronger visual effect than many smaller components. The technical specification should always be confirmed first, with colours and finishes selected only after the correct application is established.
Is a Kineo Wheel Set Right for Your Tuareg?
Not every rider needs aftermarket wheels. The standard Aprilia Tuareg 660 already has a capable tubeless spoked-wheel system, so replacing it should be a deliberate decision based on the wheel construction, model-specific configuration and custom appearance the rider actually wants.
For the Aprilia Tuareg 660 Rally, the decision can be different because its original wheel setup uses tubes. A dedicated Kineo tubeless system may therefore provide an additional reason to upgrade, provided the exact Rally application is confirmed.
01 TUBELESS DESIGN
02 MODEL-SPECIFIC
03 CUSTOM FINISHES
The best approach is to start with the motorcycle rather than the wheel catalogue. Confirm the version, production year and current hardware first, then select the correct Kineo configuration.
For riders researching Aprilia Tuareg 660 wheels, that process avoids guessing and ensures the finished wheel set is selected for the actual motorcycle rather than simply because the rim diameter appears correct.
Confirm the Tuareg. Confirm the fitment. Then build the finish.
BUILD YOUR APRILIA WHEEL SET
Configure Kineo Wheels for Your Tuareg
Start with the exact Tuareg 660 or Tuareg Rally model and production year, confirm the correct wheel application, then select your rim, hub, spoke and nipple finishes.
