Kineo Wheels for Triumph Street Twin: Complete Fitment Guide

Kineo makes tubeless spoked wheels for the Triumph Street Twin 900. Both the 2016-2018 models and the updated 2019-2022 generation.

Here’s what matters. You get that classic wire-spoke look without dealing with tubes. Real tubeless technology. Mount modern tires, run proper pressures, fix a puncture roadside if you need to. The aesthetic stays traditional. The functionality stays modern.

What Are Kineo Wheels for Triumph Street Twin?

Kineo wheels are truly tubeless wire-spoked wheels. Not converted. Not sealed with tape. Actually tubeless from the start.

The difference is in how the spokes attach. Traditional spoked wheels have nipples that penetrate through the rim. Holes in the rim bed. That’s why you need tubes. Or sealing tape that might fail.

Kineo designed their spokes to attach without putting holes where air needs to stay. The nipples sit parallel to the wheel axis. The rim stays intact. Air stays in.

Construction is CNC billet machining with 7000 series aluminum alloy. Not cast. Machined from solid material. TÜV approved for street use in Europe, which tells you something about the engineering validation behind these wheels.

Triumph Street Twin Model Compatibility

Kineo fits two generations of Street Twin 900:

• Street Twin 900 (2016-2018) — First generation
• Street Twin 900 (2019-2022) — Updated platform

Important: the wheel sizes changed between generations. You can’t use 2016 wheels on a 2020 bike. Gotta match the model year.

Installation is plug-and-play. OEM brake disc compatibility. No modifications to your Street Twin required. Pull the old wheels off, put the new ones on.

Front Wheel: 2016-2018 Models

The first-generation Street Twin takes a 3.50×17.0 front wheel with 28 spokes.

Forged hub construction. Tubeless-ready rim that accepts standard tubeless tires without any tape or sealant required. Direct replacement for the factory cast wheel.

Front Wheel: 2019-2022 Models

Here’s where people get confused. The updated Street Twin uses an 18-inch front wheel, not 17.

Specification: 2.50×18.0 with 28 spokes.

Triumph changed the front wheel size when they updated the platform. Narrower rim, larger diameter. Different look, different handling character. Your Kineo order needs to match your actual bike.

Rear Wheel Specifications

Both generations use the same rear setup: 32 spokes with integrated cush drive system and aluminum rear sprocket.

The cush drive dampens drivetrain shock. Stock feature on your Street Twin, maintained with Kineo wheels. The aluminum sprocket comes standard with OEM tooth count. Want different gearing? Custom tooth counts are available.

Key Features of Kineo Wheels

What separates these from other spoked wheel options:

• Truly tubeless — No seals required. No rim tape. The design is inherently airtight.
• Forged hub construction — Stronger than cast. Better grain structure in the metal.
• Individual spoke replacement — Swap a damaged spoke without removing the tire. Huge deal for maintenance.
• Dual tire compatibility — Run tubeless tires or tube-type. Your choice.
• ABS sensor compatible — Retains full ABS function with your stock sensors.

Tubeless Technology

The whole point of Kineo’s design. Spokes attach via nipples oriented parallel to the wheel axis. No penetration through the rim surface.

Why does this matter? Guaranteed tire sealing integrity. Not dependent on tape adhesion. Not hoping sealant holds. The rim is solid where it needs to be solid.

I’ve seen taped spoked wheels fail. Usually at the worst time. Heat cycles, age, a sharp hit. The tape lifts, air escapes. Kineo doesn’t have that failure mode.

Materials & Construction

• 7000 grade aluminum — Both rim and hub. Strong stuff. Used in aerospace applications.
• Stainless steel spokes — Corrosion resistant. Won’t rust out in wet climates.
• CNC machined finish — Precise. Consistent. Not rough casting marks.
• Anodized coating — Additional corrosion protection, especially for colored options.

Quality shows in the details. These aren’t budget wheels dressed up fancy. The materials and processes match the price point.

Customization Options

Standard black works. But you can go further.

Rim colors — Multiple options beyond black. Match your bike or contrast against it.

Hub colors — Titanium, gold, orange, red, blue, green. The hub accent catches light differently than the rim. Creates visual depth.

Spoke end colors — Eight options. Subtle detail that most people won’t notice consciously. But it contributes to overall impression.

Custom sprocket teeth — Change your gearing while you’re at it. Taller for highway cruising. Shorter for punchier acceleration. Your call.

Some riders go all black for the stealth look. Others use gold hubs on a black bike for classic cafe racer vibes. Personal preference territory.

Installation & Fitment Details

Direct bolt-on replacement for OEM cast wheels. No frame modifications. No brake changes. No headaches.

Your original brake discs mount to Kineo’s brake disc carrier system. Same rotors you’ve been using. ABS sensors maintain full OEM function because the tone rings and clearances are matched to factory specifications.

Special mounting hardware is included where needed. Kineo accounts for the differences between their wheels and stock fitment.

Most competent shops can handle the swap in an hour or two. It’s wheel removal and installation. Tire mounting if you’re changing rubber. Brake system doesn’t get touched beyond removing and reinstalling the caliper.

What’s Included with Your Kineo Wheels

Complete wheelset arrives with everything necessary:

• Forged hub
• Rim
• Spokes (already laced and tensioned)
• Brake disc carriers
• Spacers
• Bearings
• Tubeless valves
• Cush drive (rear wheel)
• Aluminum sprocket (rear wheel — OEM tooth count standard, custom available)

Nothing extra to source. Nothing left out. Open the box, mount tires, install on bike.

Lead Time & Ordering

Kineo wheels are made-to-order in Italy. These aren’t sitting on a warehouse shelf waiting. They’re built when you order.

Typical production time runs 2-8 weeks depending on your color and specification choices. Standard configurations ship faster. Full custom color combos take longer.

Seasonal variation matters. August in Italy means holidays. Factory production slows or stops. Order in July, expect delays into September. Plan accordingly if you have a deadline.

Worth the wait in my experience. You’re getting wheels built specifically for your bike, to your specifications, by people who actually know what they’re doing.

FAQs: Kineo Wheels for Triumph Street Twin

Common questions about fitting Kineo wheels to Street Twin models.

Are Kineo wheels truly tubeless for Triumph Street Twin?

Yes. Completely tubeless with no seals or tape needed.

The spokes don’t penetrate the rim surface. No holes to seal. Air stays in because there’s nowhere for it to escape.

Also compatible with tube-type tires if you prefer running tubes for some reason. But most riders go tubeless since that’s the whole point.

Can I use my stock brake discs with Kineo wheels?

Yes. Kineo’s brake disc carrier system accepts your OEM brake discs without modification.

ABS sensors work too. Same mounting, same function. Your Street Twin’s safety systems remain fully operational.

What’s the difference between 2016-2018 and 2019-2022 fitments?

Front wheel size. The 2016-2018 runs a 17-inch front. The 2019-2022 runs an 18-inch front.

Must specify your exact model year when ordering. Get this wrong and you’ll receive wheels that don’t fit. Check your registration or VIN if you’re unsure which generation you have.

Can I replace individual spokes without removing the tire?

Yes. Kineo’s spoke design allows individual spoke replacement while the wheel remains fully assembled.

Damage one spoke on the road? Replace just that spoke. Don’t need to strip the tire, break the bead, redo everything. Practical advantage over conventional spoked wheels.

What sprocket sizes are available for the rear wheel?

OEM tooth count comes standard. Matches your factory gearing exactly.

Custom tooth counts available on request. Up or down from stock depending on your riding priorities. Note that 520 chain conversion is required for wider rear rim options if you go that route.

How long does delivery take for Kineo wheels?

Production time is 2-8 weeks from order placement.

Factors affecting timeline: color selection (custom takes longer), current production queue, seasonal variations (Italian August holidays). Standard configurations on the shorter end. Full custom on the longer end.
